The first official CAD-based renders for the Samsung Galaxy S27 Ultra have leaked, offering an unfiltered look at Samsung’s next flagship strategy. The CAD drawings expose a dramatic industrial design overhaul, a surprisingly slim main chassis, and serious upgrades to display privacy, performance, and camera hardware.
Here is an in-depth breakdown of the leaked design, specs, camera configuration, and pricing.
Galaxy S27 Ultra Specs at a Glance
| Feature | Leaked Details |
| Display | 6.9-inch 2K AMOLED, 120Hz, Built-in Privacy Shield |
| Processor | Qualcomm Snapdragon 8 Elite Gen 6 |
| Main Camera | 200MP ISOCELL HP6 primary sensor |
| Secondary Cameras | 50MP Ultra-Wide + 50MP Periscope (5x Optical Zoom) |
| Battery | 5,700 mAh |
| Chassis Thickness | 7.97mm (12.53mm at the camera module) |
| Stylus | Integrated S Pen |
| Expected Price | ~$1,399 USD / ₹1,49,999 INR |
The Design Shift: A Bold New Camera Plateau
The most striking detail in these CAD renders is the rear panel redesign. Samsung has moved away from the individual floating camera rings seen on recent models in favor of a unified, raised camera island.
Ultra-Slim Body vs. Camera Projection: The main housing drops to a razor-thin 7.97mm. However, the camera module brings total thickness to 12.53mm at its peak.
Streamlined Triple Camera Layout: Samsung is streamlining the rear layout, concentrating entirely on three high-resolution sensors rather than filler depth units.
Sharper Ergonomics & S Pen: Sharp rectangular corners remain intact to house the embedded S Pen, while side bezels look noticeably thinner.
Under the Hood: Key Upgrades
Built-in 6.9-inch Privacy Display
The 6.9-inch 2K 120Hz panel reportedly features hardware-level Privacy Display technology. This system dynamically tightens viewing angles to keep sensitive screen content hidden from onlookers.
Snapdragon 8 Elite Gen 6 Power
Qualcomm’s next-gen Snapdragon 8 Elite Gen 6 sits at the heart of the S27 Ultra. The chip’s improved thermal efficiency will be crucial to sustain peak performance inside a 7.97mm frame.
200MP ISOCELL HP6 & Dual 50MP Cameras
Imaging hardware gets a big boost with Samsung’s new 200MP ISOCELL HP6 main sensor, paired alongside a 50MP ultra-wide lens and a 50MP periscope telephoto (5x optical zoom).
Bigger 5,700mAh Battery
Despite shaving off body thickness, internal optimization allows space for a 5,700mAh battery—a direct nod to heavy power users wanting multi-day endurance.
Pricing & Market Positioning
With an estimated launch price of ~$1,399 / ₹1,49,999, the Galaxy S27 Ultra maintains its position at the peak of ultra-premium flagships. The combination of hardware-level privacy, upgraded optics, and a major chassis redesign aims to justify the top-tier pricing.
Read our full analysis and view high-resolution render breakdowns at NokiaPowerUser.
Final Take: Form vs. Function
Samsung’s CAD leak reveals a clear direction: engineering an ultra-thin 7.97mm flagship without compromising on battery capacity or stylus functionality. While the 4.5mm camera projection will generate debate among minimalists, the hardware gains suggest a massive generation-over-generation leap.
